2-11
2.5.3 Fuse Boxes
1
2
4
3
5
6
Left Fuse Box Assembly
106-5505/106-6678
Right Fuse Box Assembly
106-5506/106-6679
ITEM PART # COMPONENT
1 810-0519 Hinge
2 807-3970 Block, 3 Pole 600V 175A Terminal
3 807-0501 Fuse Block, Buss #2968 3-Pole
4 807-2240 Fuse, 60 AMP 300VAC
5 807-0070 Terminal, Ground Lug
6 807-0128 Bushing, Insulating Heyco
