2.5.1 Component Boxes cont.
ITEM PART # COMPONENT
1 106-5592 Box Assembly, Component
2 200-3300 Bracket, Component Box Strain Relief
√ 3 807-0012 Relay, Filter 18A, 1/3HP 24VAC
√ 4 807-0670 Relay, Filter DPDT 20A 24VAC
√ 5 807-4770 Relay, 240V DPDT 20A
√ 807-4346 Relay, 120V DPDT 20A (used in Canadian models only)
6 807-0037 Terminal, ¼-inch Push-on
7 807-0121 Bushing, Heyco Plastic AB-625-500
8 807-0922 Holder, Buss Fuse HPS Screw Type
√ 9 807-2278 Fuse, 20 Amp
10 810-2446 Plug, Button .50 Heyco Double “D”
√ 11 807-4036 Switch, Power
807-3575 Plug, Carling Switch Hole (used on some models without a switch)
12 807-1947 Plug, Button .875 Dome
13 807-1321 Holder, AGC Panel Mount ¼” Fuse (Some models use item 10 here.)
14 807-1597 Fuse, 3 AMP Slow-Blow
15 106-5750 Harness Assembly, RE FV Control
16 106-5751 Harness Assembly, RE DV Control
√ 17 807-0855 Transformer, 100-120V 12V 20VA
√ 18 807-0800 Transformer, 100-120V 24V 50VA Filter
√ 19 807-0680 Transformer, 208-240V 24V 20VA Filter
√ 20 807-2191 Transformer, 208-240V 12V 30VA
√ 21 807-0979 Transformer, 208-240V 12V 43VA
√ 22 807-2180 Transformer, 100-120V 50VA Filter
√ 23 812-2126 Transformer, 208-250V 24V 75VA w/o Fuse (Used in DV component boxes)
√ 24 807-4967 Transformer, 100-120V 24V 75VA (Used in DV component boxes)
√ 25 807-4968 Transformer, 208-250V 24V 75VA (Used in DV component boxes)
√ 26 826-2260 Interface Board Standard Full or Dual Vat (includes sound harness)
* 106-6501 Fallback Controller Assembly
* 807-4403 Speaker, 4-Watt SMT
27 809-0349 Spacer, 4mm X 6mm Aluminum
28 816-0217 Paper, Insulating Terminal Block
29 810-0045 Bushing, .875 Diameter 11/16”
30 806-9495SP Terminal Block
√ 31 807-4346 Relay, DPDT 20A 120V (used for control power reset in right hand boxes only
in domestic and Canadian units)
√ 807-4770 Relay, DPDT 20A 240V (used for control power reset in right hand boxes only
in international units; some international units have one located in each control
box)
32 807-2659 Switch, Momentary (used to reset control power; located in box over JIB only.)
33 230-5038 Guard, Switch
√ 34 807-1174 Fuse, 250V 3 AMP Slow-Blow
35 810-2445 Plug, Button .625 Heyco Double “D”
36 220-8467 Guard Finger OCF with JIB (use 220-5038 for OCF without JIB)
√ 37 807-4678 Switch, Momentary JIB Reset
* 826-2249 RE Hood/Ansul Interlock Kit (includes terminal block, wires and connectors)
* Not illustrated.
√ Recommended parts.
