2-14
2.5.5 Element Assemblies and Hardware cont.
ITEM PART # COMPONENT
1 Element Kits – includes gaskets, grommets, tie wraps, screws and nuts.
826-2198
200V 17.0 kW (220V 8.5kW used in some export 3-phase 4-wire WYE
units)
826-2201 200V 18.5 kW
826-2192 208V 17.0 kW
826-2197 208V 18.5 kW
826-2200
220V 17.0 kW (220V 8.5kW used in some export 3-phase 4-wire WYE
units)
826-2193 230V 17.0 kW
826-2199
230V/400V 7.0 kW/8.5 kW(220V 8.5kW used in some export 3-phase 4-wire
WYE units)
826-2194 240V 17.0 kW
826-2204 400V 8.5kW
826-2195 440V 17.0 kW
826-2202 440V 18.5 kW
826-2196 480V 17.0 kW
826-2203 480V 18.5 kW
√ 2 826-2212 Probe, Temperature RE – includes tie wraps and grommet.
807-4324 Probe, Temperature Fast Ready
3 816-0681 Grommet, Probe
4 816-0480 Plug, .375-inch Dome
5 816-0688 Gasket, Element
6 809-1003 Screw, 10-32 X ⅜-inch Hex Head SS
* 809-0766 Nut, 10-32 Keps Hex Head SS
* 230-4028 Wrench, Element Tube Nut Spanner
7 230-3714 Bracket, Temperature Probe 7.0 kW
230-0784 Bracket, Temperature Probe 8.5
8 809-0518 Screw, 8-32 X ⅜-inch Slotted Hex Head
9 910-2042 Clamp, Element (Short)
10 230-0781 Clamp, Element (Long)
11 230-0780 Support, Full-Vat Element Rear
12 823-5621 Support, Full-Vat Element Front
13 809-0567 Tie-Wrap, Metal
14 810-1212 Pin, .125 X .5-inch Split
15 230-4903 Support, Dual-Vat Element Rear Dual Vat
16 823-8085 Support, Dual-Vat Element Front Dual Vat 14kW
823-8086 Support, Dual-Vat Element Front Dual Vat 17kW
17 810-3030 Spring, Element Lift Left
810-3131 Spring, Element Lift Right
18 220-1190 Bracket, Lower Spring Single Foot Print
220-0464 Bracket, Lower Spring
19 220-0733 Bracket, Lower Spring Mating
20 810-1233 Handle, Element Lift
* Not illustrated.
√ Recommended parts.
