Control Panel
77
Product Overview
2
Control Panel
11
12
13
14
15
16
17
18
19
20
21
22
23
9
10
8
7
1
2
3
45
6
24
25
No. Component Function
1 <Services Home> button Press this button to display the Services Home screen.
Note • You can change the services displayed on the Services Home screen. For
more information, refer to "1 Before Using the Machine" > "Customizing
the Control Panel" > "Customizing the Button Layout" in the
Administrator Guide.
2 Touch screen Displays messages required for operation, and buttons for various features.
You can directly touch the touch screen to instruct operations and set
features.
3 <Log In/Out> button Lights up when a user is authenticated in the System Administration mode,
the Authentication mode, or the Accounting mode. Press this button to
display the User ID entry screen for entering the System Administration
mode, the Authentication mode, or the Accounting mode. Also press this
button to exit these modes.
4 <Job Status> button Press this button to check or cancel the current job, to check or print stored
jobs, or to check completed jobs.
5 <Machine Status> button Press this button to check the machine status and meters, to check the
status of the consumables, and to print reports.
Note • By pressing the <Machine Status> button when you exchange the
consumables, you can make the output device exit the Power Saver
Mode and check the latest status of the consumables.
6
<Power
Saver>
button
When the machine is not used
for a while, it enters the Power Saver mode to reduce power consumption. When the Power Saver mode is active, the
<Power Saver> button lights up.
Press this button to enter or exit the Power Saver mode.
To Next Page
