Basic Operation 29
10
Secure the optional 550 sheet feeder to the printer by tightening the two screws provided with the feeder with a coin
or similar object.
11
Insert the standard 250 sheet tray into the printer, and push until it stops.
IMPORTANT:
• Do not use excessive force on the tray. Doing so could damage the tray or the inside of the printer.
12
Insert the bypass tray into the printer, push until it stops, and close the cover.
13
Apply the label to the upper part of the operator panel on the printer.
14
Reconnect all cables into the rear of the printer and turn on the printer.
NOTE:
• The printer will automatically detect the attached tray but will not detect the paper type.
15
Print the Printer Settings page to confirm the optional 550 sheet feeder is installed correctly.
a
Press the (Menu) button.
b
Select Report / List, and then press the button.
c
Select Printer Settings, and then press the button.
The Printer Settings page is printed.
