System expansions
Removing and installing the fan
i
Your workstation may or may not have a fan, depending on the configuration.
The fan must be removed whenever you install a board or upgrade the main memory.
Remove the fan
2
1
► Open the casing (see "Opening the casing").
► Loosen the screw (1).
► Remove the fan in the direction of the arrow (2).
36 A26361-K665-Z126-1-19, edition 1
