Fujitsu Siemens Computers CELSIUS M430 - Replacing the Floppy Disk Drive

System expansions
Replacing the floppy disk drive
► Open the casing (see "Opening the casing").
► Remove the front (see "Removing the front panel").
► Disconnect the cables connected to the floppy disk drive.
► If it is present, pull the cable of the front USB or USB-audio interface from the mainboard (see
also the manual for the mainboard).
Removing the floppy disk drive
1
1
► Press the EasyChange rails in the direction of the arrows (1).
► Pull the floppy disk slide-in module out of the casing (2).
50 A26361-K665-Z126-1-19, edition 1
