Technical data
Electrical data
Regulations complied with: EN 60950
UL 60950
CSA 22.2 No.950
Protection class: I
Rated voltage range (automatic, power supply
250 and 300 W):
100 V -240 V
Frequency: 50 Hz - 60 Hz
Max. rated current
● Workstation with monitor socket:
100 V -240 V/7.0 A -3.5 A
● Monitor socket (output): 100 V -240 V/3.0 A -1.5 A
Dimensions
Width/depth/height: 205 mm/504 mm/385 mm
Weight
with the basic configuration approx. 15 kg
Environmental conditions
Environment class (3K2)
Environment class (2K2)
DIN IEC 721 part 3-3
DIN IEC 721 part 3-2
Temperature:
● Operating (3K2)
● Transport (2K2)
15 °C .... 35 °C
-25 °C .... 60 °C
Condensation in operating must be avoided.
Clearance required to ensure adequate ventilation:
● left/right/above
● front
● rear
min. 200 mm
min. 200 mm
min. 200 mm
i
The data sheet of the workstation contains further technical data. You will find the data
sheet on the internet at
http://www.fujitsu-siemens.com/
A26361-K665-Z126-1-19, edition 1 77
