System expansions
Removing a board
► Open the casing (see "Opening the casing").
For workstations with a fan only:
► Remove the fan (see "Remove the fan").
► Disconnect the cables connected to the board.
1
2
3
► Press the unlocking mechanism (1) down and open the locking rail (2). The word "PRESS" is
embossed on the unlocking mechanism.
► Pull the board out of the slot (3).
► Place the board into appropriate packaging.
!
For cooling, protection against fire, and in order to comply with EMC (electromagnetic
compatibility) regulations, you must refit the slot cover.
40 A26361-K665-Z126-1-19, edition 1
