System expansions
Removing an accessible drive
► Open the casing (see "Opening the casing").
► Remove the front (see "Removing the front panel").
1
1
► Pull the data and the power supply connectors from the desired drive.
► Press the EasyChange rails together (1) and pull the drive out of the casing (2).
► If necessary, make the required settings on the remaining hard disk drive.
48 A26361-K665-Z126-1-19, edition 1
