Fujitsu Siemens Computers CELSIUS M430 User Manual

System expansions
► Press the EasyChange rails into the provided holes.
► Push the accessible drive into the casing (1) until the EasyChange rails engage.
► Plug the data and the power supply connectors into the drive. Make sure the polarity is correct.
► Attach the front panel (see "Attaching the front panel").
► Close the casing (see "Closing the casing").
i
With the upper three accessible drives, the EasyChange rail is attached at the bottom of
the module.
The rail is attached at the centre of the module on the lowest drive.
All rails are mounted correctly on delivery.
It may be necessary to modify the entry for the drive in the
BIOS Setup.
A26361-K665-Z126-1-19, edition 1 47
