Fujitsu Siemens Computers CELSIUS M430 User Manual

System expansions
Removing a hard disk drive
► Open the casing (see "Opening the casing").
► Remove the cover (see "Removing the cover ").
► Disconnect all cables connected to the drive (data cable, power supply cable).
1
1
2
► Press the EasyChange rails in the direction of the arrows (1).
► Pull the hard disk drive out of the carrier (2).
► Pull the EasyChange rails off the hard disk
drive.
► If necessary, make the required settings on
the remaining hard disk drive.
► Close the casing (see "Closing the casing").
► Attach the cover (see "Installing the cover plate").
i
It may be necessary to modify the entry for the drive in the
BIOS Setup.
56 A26361-K665-Z126-1-19, edition 1
