Fujitsu Siemens Computers CELSIUS M430 User Manual

System expansions
Installing a SmartCard reader
1
2
► Slide the SmartCard reader into the supplied
mounting (1) with the component side
upwards and fix it in place with the
screws (2).
► Connect the data cable to the SmartCard
reader.
1
2
► Place the carrier on the guide clips in the casing.
► Slide the carrier in the direction of the arrow as far as it will go (1).
► Fasten the mounting to the casing with the screws (2).
► Connect the plug of the SmartCard data cable to the mainboard (see the manual for the
mainboard).
► Attach the front panel (see "Attaching the front panel").
► Close the casing (see "Closing the casing").
58 A26361-K665-Z126-1-19, edition 1
