Fujitsu Siemens Computers D1691 User Manual

Chapter 4: BIOS Setup
44 A26361-D1691-Z120-1-7619, Edition 1
Setup Item Selections (Default
values are in bold)
Item Specific Help
Mode: ECP
EPP
Bi-directional
Output only
Set the mode for the parallel port.
Base I/O
Address:
378
278
3BC
Set the base I/O address for the parallel port.
Interrupt: IRQ5
IRQ7
Set the IRQ for the parallel port.
DMA channel: DMA1
DMA3
Set the DMA channel for the parallel port.
4.3.14 - Advanced Submenu PCI Configuration
PCI Express x16: [Auto]
► PCI Device, Slot #1
► PCI Device, Slot #2
► PCI Device, Slot #3
► PCI Device, Slot #4
► PCI Device, Slot #5
► PCI/PNP IRQ Exclusion
Setup Item Selections (Default
values are in bold)
Item Specific Help
PCI Express x16
Auto
Disabled
Enabled
Configures the PCI Express x16 Slot:
[Auto]
BIOS configures the slot.
[Disabled]
Slot is disabled.
[Enabled]
Slot is always enabled.
PCI Device, Slot #1 - Configuration of the Specific PCI device.
PCI Device, Slot #2 - Configuration of the Specific PCI device.
PCI Device, Slot #3 - Configuration of the Specific PCI device.
PCI Device, Slot #4 - Configuration of the Specific PCI device.
PCI Device, Slot #5 - Configuration of the Specific PCI device.
PCI/PNP IRQ Exclusion - Reserve specific IRQs for use by legacy devices.
