Appendix II: Post Error Code for BIOS
60 A26361-D1691-Z120-1-7619, Edition 1
Appendix II: Post Error Code for BIOS
POST (hex) Description
CFh:
Test CMOS R/W functionality.
C0h:
Early chipset initialization:
– Disable shadow RAM
– Disable L2 cache (socket 7 or below)
– Program basic chipset registers
C1h:
Detect memory
– Auto-detection of DRAM size, type and ECC.
– Auto-detection of L2 cache (socket 7 or below)
C3h:
Expand compressed BIOS code to DRAM
C5h:
Call chipset hook to copy BIOS back to E000 & F000 shadow RAM.
01h:
Expand the Xgroup codes locating in physical address 1000:0
03h:
Initial Superio_Early_Init switch.
05h:
1. Blank out screen
2. Clear CMOS error flag
07h:
1. Clear 8042 interface
2. Initialize 8042 self-test
08h:
1. Test special keyboard controller for Winbond 977 series Super I/O chips.
2. Enable keyboard interface.
0Ah:
1. Disable PS/2 mouse interface (optional).
2. Autodetect ports for keyboard & mouse followed by a port & interface swap
(optional).
3. Reset keyboard for Winbond 977 series Super I/O chips.
0Eh:
Test F000h segment shadow to see whether it is R/W-able or not.
If test fails, keep beeping the speaker.
10h:
Auto detect flash type to load appropriate flash R/W codes into the run time area
in F000 for ESCD & DMI support.
12h:
Use walking 1’s algorithm to check out interface in CMOS circuitry. Also set real-
time clock power status, and then check for override.
14h:
Program chipset default values into chipset. Chipset default values are
MODBINable by OEM customers.
16h:
Initial onboard clock generator if Early_Init_Onboard_Generator is defined.
See also POST 26h.
