Connect the monitor, mouse and keyboard Preparing for use
A26361-K657-Z101-4-7619 9
1
2
1
Ê Depending on the connector supplied with your monitor, plug the monitor's power cable into
either the PC (1) or the mains supply (2).
!
You may connect a monitor with a rated current of less than 1.5 A (230 V) or 3 A (115 V).
The rated current for the monitor is given on the monitor itself and in the operating manual
for the monitor.
Connecting a keyboard
Depending on the equipment level selected, your PC will be supplied with a standard keyboard or a
USB keyboard.
Connecting standard keyboard
Use the supplied keyboard cable only.
Ê Plug the other end of the keyboard cable (square plug) into the socket on the underside of the
keyboard.
Ê Plug the round plug of the keyboard cable into the keyboard port of the PC.
