FNC001583_Rev_03
Figure 11
RU Pole Mount Kit
e RU wall mounting kit contains the parts and installation hardware detailed in the following table.
Table 35
Pole Mount Kit Assembly Legend
Item Description
1 Mounting Plate Adapter
2 Bolt, HEX, HD, 3/16-16 x 10.0 L, 18-8 SS
3 Washer, Split, M10, SS
4 Bolt, HEX HD, M10 x 30L, SS
5 Bolt, HEX HD, M10 x 40L, SS
Installation
Mounting
