Table 35 (Cont.)
Pole Mount Kit Assembly Legend
Item Description
6 Crossmember (Large)
7 Crossmember (Small)
8 Insulator, Washer, Flat, M10
9 Insulator, Washer, Flat, M10
10 Washer, Flat, M10, SS
11 Wall Mount Plate
12 .375 Flat Washer
13 M10 SS Flat Washer
14 .375 Lock Washer
15 M10, SS, Split Washer
16 Eye Bolts
17 Radio Unit
18 L-Brackets with Hardware
e following gure shows how to mount an RU to a outdoor wall using a wall mounting kit.
