FUJITSU DL3100
C-22 User’s Manual
Function
Command
Select 120-dpi, double-speed graphics
ESC Y (nL nH
d1 d2 . . . dk)
Prints bit-image graphics in 8-dot columns, at a density
of 120 horizontal by 60 vertical dpi,according to the
following parameters:
nL, nH Specify the total number of columns (k) of
graphics data following, according to the formula
k = ((nH × 256) + nL)
nH = INT(k/256)
nL = MOD(k/256)
d1 . . . dk Bytes of graphics data
(0 ≤ nL ≤ 255, 0 ≤ nH ≤ 31, 0 ≤ d ≤ 255)
Notes
• The ESC * 2 command is identical to this command;
use ESC * 2 instead of this command.
• The speed is double because consecutive horizontal
dots cannot be printed; the printer ignores the second
continuous horizontal dot.
• The dot density printed with this command can be
redefined with the ESC ? command.
Select 240-dpi graphics
ESC Z( nL nH
d1 d2 . . . dk)
Prints bit-image graphics in 8-dot columns, at a density
of 240 horizontal by 60 vertical dpi,according to the
following parameters:
nL, nH Specify the total number of columns (k) of
graphics data following,according to the formula
k = ((nH × 256) + nL)
nH = INT(k/256)
nL = MOD(k/256)
d1 . . . dk Bytes of graphics data
(0 ≤ nL ≤ 255, 0 ≤ nH ≤ 31, 0 ≤ d ≤ 255)
Notes
• The ESC * 3 command is identical to this command;
use ESC * 3 instead of this command.
• The speed is double because consecutive horizontal
dots cannot be printed; the printer ignores the second
continuous horizontal dot.
• he dot density printed with this command can be
redefined with the ESC ? command.
