FUJITSU DL3100
User’s Manual C-25
Function
Command
f. a check digit and OCR control
Bit
Description
Value
Function
0
Indicate if the check
digit is attached *1
0
Attached
1
Not attached
1
OCR (by default,
OCR-B)
0
Printed
1
Blank
2
Position of flag
characters for EAN,
UPC. *3
0
Barcode’s left
centererd.
1
Below barcode’s left
side
*1 Bit 0 is ineffective for Codabar, by default without
check digit. Usually define Bit 0 = 0 for EAN13,
EAN8, UPC Type A, UPC Type A with check
character.
*2 Reserve additional XX spaces to print the flag
character if bit 1 = 0.
*3 EAN13, EAN8, UPC Type A, UPC Type A with
check character can print it .
