FUJITSU DL3100
User’s Manual C-37
• If bits 1 and 2 of n4 are 00 and bit 8 is set to 0 the
bytes that make up the character definition define
rows 2 to 9 of the grid, the most significant bit
representing the second dot, and the least significant
bit representing the ninth dot down. Simply set a bit
to 1 to print a dot in that position on the grid, or to 0
• If bits 1 and 2 of n4 are 01 the least significant bit of
each data byte is replicated in rows 9 to 12 of the
• If bits 1 and 2 of n4 are 10 the bits 1 to 4 of each
data byte are replicated in rows 9 to 12 of the grid.
• Bits 5 to 7 of n5 specify the number of columns left
blank to the left of the defined character in
proportional spacing mode. Up to seven columns
• Bits 1 to 4 of n5 specify the width in columns of the
defined character in proportional spacing mode.Up
to fifteen columns can be used to define the
• Downloaded characters are selected using the Esc I
command and then printed by sending the
appropriate character codes.
0 (cH) (cL)
The digits 4 0 0 0 (decimal), 04 00 00 00
(hexadecimal) are constants.
See below table for the value of cH and cL
