Fujitsu DL3100 User Manual

FUJITSU DL3100
User’s Manual C-41
Function
Command
Printing graphics
Select graphics mode
ESC [ g nL nH
mode data
Use this command to select the mode and horizontal
density for dot matrix graphics.
• nL and nH identify the number of bytes in mode
and data.
• mode is the vertical wire count and the horizontal
density in dots per inch.
Select mode from the following table.
Dec
Hex
Horizontal Density
Wires
0
0
60
8
1
1
120
8
2
2
120
8
3
3
240
8
8
8
60
24
9
9
120
24
11
0B
180
24
12
0C
360
24
• data is the bit-mapped graphics information. The
printhead moves at half the speed of mode 2,
giving better resolution.
Select bit image
ESC * mode
nL nH data
When AGM mode is selected, prints dot-graphics in
8, 24-dot columns, mode is the same as the mode
value of the command ESC [ g
• nL and nH identify the number of bytes in mode
and data.
Select mode from the following table.
m(dec)
Horizontal density (dpi)
Wires
0
60
8
1
120
8
2
120
8
3
240
8
4
80
8
6
90
8
32
60
24
33
120
24
38
90
24
39
180
24
40
360
24
