FUJITSU DL3100
User’s Manual 2-3
3. Install the recess positions ①-② on the ribbon cassette
into the printer mounting. Press the ribbon frame to install
it properly.
4. Pull out the ribbon guide stuck on the ribbon case with
holding both ends of the ribbon guide.
5. Install the ribbon guide stuck behind the print head, turn
the ribbon cartridge knob in the clockwise direction and
move the carriage left and right to ensure the carriage and
ribbon fabric is taut.
