How to operate the Sound Adjustment Mode
IX
Crossover adjustment (X-Over)
With the 4-speaker system, the frequencies of the front speaker
HPF (High Pass Filter) and woofer LPF (Low Pass Filter) can be
adjusted. With the 3-way speaker system (a speaker system
combining a high range tweeter, a mid range speaker and a low
range woofer), the integration between the sound of the speakers is
improved by adjusting playback zones using tweeter HPF, mid-
range HPF and LPF and woofer LPF.
Turn the [SEL] button to select X-Over.
The selected item will be highlighted.
Press the [SEL] button.
The mode will change to crossover adjustment mode.
Press the [SEL] button to select the crossover
adjustment channel.
Each time the button is pressed, the selection changes in the
following order.
Speaker layout: 3-way speaker system
Hi ➔ M-LPF ➔ M-HPF ➔ Low ➔
Speaker layout: 4-speaker system
Front ➔ Rear ➔ Woofer ➔
[SEL] button
