Fujitsu ECLIPSE CD8455 - Changing Illumination Color

53
Basic operation
IV
Changing illumination color
You can change the button illumination color in the following way.
Turn the [SEL] button to select ILL.
The selected item will be highlighted.
Press the [SEL] button.
The screen for changing the illumination color will appear.
Turn the [SEL] button to adjust the illumination
color.
When the button is turned, the illumination color changes in
the following order.
Press the [SEL] button.
The selected settings will take effect.
Press the [RTN] button.
At this time, other adjustments can also be made in display
adjustment mode.
Press the [DISP] or [RTN] button to exit display
adjustment mode.
[SEL] button
[DISP] button [RTN] button
Blue/Red Blue/Green
Blue/Amber
All Red
All Green
