Fujitsu ECLIPSE CD8455 - Page 228

228
Mounting instruction
1) CD8455 Receiver, used alone
Caution Never connect the power supply to the speaker leads, otherwise it causes damage to the main unit.




13
MICROPHONE
L SIDE
R SIDE
DIGITAL IN
NON-FADER REAR FRONT
CD8455
ANTENNA PLUG
White(+)
White/Black(-)
Gray(+)
Gray/Black(-)
Green(+)
Green/Black(-)
Purple(+)
Purple/Black(-)
Brown
FL FR RL RR
TO STEERING REMOTE CONTROL
Brown/Black
Red Yellow Blue Orange/White Blue/White
Black
TO ACC (Power supply)
TO BATTERY+12V (Permanent supply)
TO POWER ANTENNA RELAY (supply)
TO HEAD LIGHT SWITCH (supply)
TO TURN ON LEAD OF EACH UNIT (supply)
TO GROUND
INTERCONNECTING CABLE
16P
10
9 8
7
14
1
2
3
4
6
5
15
