Fujitsu PRIMERGY TX200 S6

TX200 S6 Options Guide 105
Conversion from a floorstand model to a rack model
Figure 88: Removing the screw of the side lock
Ê Remove the screw.
Figure 89: Removing the side lock
Ê Pull the side lock inward (1) and downward (2) and take it out.
I The side lock and the screw are no longer required.
