FUJITSU PSWITCH User’s Guide
16 December/2018
Figure 2-3: Attachment of rack rail
2.1.1.2. Rack Mounting
Insert this device from the rear side of the rack.
You can see the unit label on the L-shaped bracket from the rear side of
the rack.
Figure 2-4: Label
MODEL. PY-SWX48T
SERIAL. MAGU******
Label : on which the model name and the serial number are written.
PSWITCH
V
V
