Fujitsu ScanSnap S1300 User Manual

Using the ScanSnap in Various Ways (for Windows users)
150
2. Place the documents at the center of the ADF paper chute (cover).
z Place all documents over one another above the pick roller (center).
Documents that are not placed above the pick roller cannot be fed.
z Adjust the side guides to the widest document to be scanned.
z Carefully load small documents that cannot reach the side guide straight into the ADF
paper chute (cover). If the documents are skewed during scanning, the quality of
scanned image data may be degraded (partly lost image data/slant lines produced) or
scanned image data may be output in a different size than the original. If you have
difficulties in scanning the documents straight, it is recommended to scan documents in
several batches, documents of the same width being in the same batch, and enable
continuous scanning.
z Note that documents that cannot be guided by the side guide may cause paper jams.
Width of the pick roller

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
