Fujitsu ScanSnap S1300 User Manual

Setting the ScanSnap (for Windows users)
56
■ Saving Scan Settings
You can save up to 20 sets of pre-defined settings called profiles in the Left-Click Menu.
You can easily retrieve and use the saved profiles by simply clicking the ScanSnap Manager
icon .
Once the frequently used scan settings are saved as profiles, you do not have to open the
ScanSnap setup dialog box to change settings every time you perform scanning. You can
easily switch to an appropriate profile you want by just clicking on it.
The procedure is as follows:
The description here applies only when the Quick Menu is not used.
Only one profile can be saved when scanning with the Quick Menu. For information on how to
change scan settings, refer to "Changing the Scan Settings" (page 53).
Left-Click menu

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
