Fujitsu ScanSnap S1300 User Manual

Using the ScanSnap in Various Ways (for Windows users)
160
z Make sure to cover the entire character string when marking it.
Mark sections so that the entire section is evenly colored.
z Do not mark more than ten sections per page.
Good example:
Bad example 1:
(does not cover the
entire section)
Bad example 2:
(unevenly colored)
z When you use colors such as pink or yellow for marking, the marked sections may not be
recognized as keywords. In that case, try using a blue or a green highlight pen.
z Use a blue highlight pen for documents with dark background colors such as newspapers.
Marked sections may not be detected when a color other than blue is used.
z For the following document types, marked sections cannot be recognized and set as
keywords:
- Color documents such as catalogues or pamphlets
- Documents in which two or more colors are used for marking
- Documents containing colors other than for marking (pens other than highlight pens are
used or the document is stained)
- Documents with too many marked sections on a single page
z The following types of marked character strings cannot be set as keywords:
- The size of marked section is outside the supported range
- Character strings framed by a highlight pen
- The marking is irregular (e.g. skewed)
- Multiple marked sections are too close to each other
- The color of the highlight pen is too pale or the color has faded
z When you mark more than one character string, make sure to leave a gap of at least 5 mm
between the marked sections. Marked sections that are too close to each other may be
detected as one marked section.
z In the following case, character strings surrounding marked sections may be set as
keywords:
- Marked section overlaps the line above and below
z In the following cases, unmarked character strings may be set as keywords:
- Color documents such as catalogues or pamphlets
- Documents with color text, diagrams, pictures, tables and lines
- Documents containing sections framed by highlight pen
- Stained documents
z Increase the resolution when you have trouble setting the keywords correctly.
z Keywords set for a PDF file can be checked in the ScanSnap Organizer Main Window
(thumbnail view), or in [Document Properties] of Adobe Acrobat / Adobe Reader.

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
