Fujitsu ScanSnap S1300 User Manual

About Actions (for Mac OS users)
225
3. Click the [Apply] button in the ScanSnap setup window.
4. Click the [ ] button in the upper left corner or press the [esc] key to
close the ScanSnap setup window.
5. Load the document into the ScanSnap.
For details, refer to "Paper Sizes of Documents" (page 26) and "How to Load
Documents" (page 28).
6. Press the [Scan] button on the ScanSnap.
D Scanning starts.
D The following window appears and conversion is started.
D When the conversion is completed, Word or Excel starts up, displaying the converted
document in the applicable format.
The ScanSnap setup window also closes when you press the [Scan] button on the
ScanSnap.
z It is recommended to select [Better (Color/Gray: 200 dpi, B&W: 400 dpi)] or higher
resolution for [Image quality] in the [Scanning] tab in the ScanSnap setup window.
z Word documents are saved in RTF format (.rtf) and Excel documents in XLS format
(.xls).

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
