Fujitsu ScanSnap S1300 User Manual

Cleaning the Inside of the ScanSnap
285
Turn on the ScanSnap before cleaning the following rollers by rotating them:
z Feed roller (× 2)
Clean lightly taking care not to damage the surface of the rollers. Take particular care
in cleaning the rollers since foreign substances left on the rollers negatively affect the
feed performance.
z Eject roller (× 2)
Clean lightly taking care not to damage the surface of the rollers. Take particular care
in cleaning the rollers since foreign substances left on the rollers negatively affect the
feed performance.
Press the [Scan] button for three seconds with the ADF top section open to activate the
cleaning mode. In this mode, pressing the [Scan] button seven times rotate the feed and
eject rollers one full turn.
3. Close the ADF top section.
D You should hear the ADF top section click when it returns to its original position.
Connect the power cable or USB bus power cable only when cleaning the feed rollers
and eject rollers.
Make sure that the ADF top section is completely closed. Otherwise, paper jams or
other feeding errors may occur.
ADF paper chute (cover)
ADF top section

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
