Fujitsu ScanSnap S1300 User Manual

How to Load Documents
30
6. Load documents in the ADF paper chute (cover).
Load documents face-down (so that you have the back of the last page facing you) and
top-first in the ADF paper chute (cover). Do not load documents beyond the reference
marks within the side guides.
7. Adjust the side guides to the width of documents.
Move the side guides so that there is no gap between the edges of the documents and
side guides on both sides.
Otherwise, documents may be scanned skewed.
Right-click the ScanSnap Manager taskbar icon or ,
and select [Scan Button Settings]. In the ScanSnap setup
dialog box that appears, click the [Detail] button, select the
[Scanning] tab, and then click the [Option] button. In the
[Read mode option] dialog box, check whether the [Set the
document with its face up] check box is selected. If so, load
documents face-up and bottom edge first.
In Windows 7, the ScanSnap Manager icon is displayed in
the menu that appears when you click in the taskbar.
Side guide
Document

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
