Chapter 5 Information About Hardware of M4000/M5000 Servers 111
TABLE 5-2 Hardware Documentation Updates
Title Page Number Update
SPARC Enterprise
M4000/M5000 Servers
Installation Guide
2-8 "B-type plug" in the Note in "2.2.2 Cable Connections" should be
substituted with "the plug with lock function."
SPARC Enterprise
M4000/M5000 Servers
Service Manual
B-2 The description for CPU Module in Table B-1 will add the
following:
At least one CPU Module (CPUM) is required on each eXtended
System Board (XSB). The XSB includes the CPU, memory, and
optional I/O. The XSB can be set to one of two logical
configurations: uni-XSB or quad-XSB mode. In the uni-XSB
mode, the M4000 server has one configurable XSB and the M5000
server has two separate configurable XSBs. For more information
on the rules for system configuration, refer to the SPARC
Enterprise M3000/M4000/M5000/M8000/M9000 Servers
Administration Guide.
