126 SPARC Enterprise Mx000 Servers Product Notes for XCP Version 1121 • February 2016
Method of Securing the Cabinet to the Floor Surface
Vibration-proof Bracket
■ order number: CA06620-H901
By specifying the above, you can issue an order to get the following four kinds of
parts. (You should order the bolt separately.)
■ Fixing bracket: C230-4130-X514 (x4)
■ Bushing: C230-4080-X003 (x4)
■ Metal washer: F6-WB12-121 (x4)
■ Metal washer: F6-WM12-121 (x4)
■ Bolt: F6-B12-***121 (Bolt diameter: M12)
***= Bolt length (mm)
The bolt length must be specified here.
Note – Consult with the company that constructed the building because the length
depends on the structure of the building.
Vibration-proof Feet
■ order number: CA06620-H902
By specifying the above, you can issue an order to get the following parts. (You
should order the bolt separately.)
■ F6-DA6G (x4)
Change this board leg (height adjustment leg) to the "F6-DA6G" and tighten the bolt
from under the floor.
■ Bolt diameter: M20
Bolt length: 15 mm + floor thickness
Note – Consult with the company that constructed the building because the length
depends on the structure of the building.
