Chapter 6 Information About Hardware of M8000/M9000 Servers 121
M9000 Servers Installation Area
FIGURE 1-13 M9000 Server (Base Cabinet) Installation Area
M9000
(Base cabinet)
Service area
Service area
Unit: mm (inch)
900 (35.4)
900 (35.4)
1260 (49.6)
3060 (120.5)
850 (33.4)
Front
