Chapter 6 Information About Hardware of M8000/M9000 Servers 125
FIGURE 7-4 IOU Mounting Locations (Front of M9000 with the Expansion Cabinet)
Miscellaneous Information
Cabinet Stabilization Measures
This section shows useful methods of securing an M8000/M9000 server to prevent it
from shifting due to vibration.
IOU#0
IOU#2
IOU#4
IOU#6
IOU#8
IOU#10
IOU#12
IOU#14
To Next Page
