120 SPARC Enterprise Mx000 Servers Product Notes for XCP Version 1121 • February 2016
Updates of SPARC Enterprise M8000/M9000 Servers
Site Planning Guide
The following information supersedes the information in the SPARC Enterprise
M8000/M9000 Servers Site Planning Guide
TABLE 6-3 Hardware Documentation Updates
Title Page Number Update
SPARC Enterprise
M8000/M9000 Servers
Overview Guide
1-6 The description about Hardware RAID function will add the
following:
Two hard disks which are connected to the IOU onboard device
card (IOUA) can be constructed as a single logical volume. The
mirrored configuration of the constructed logical volume can
secure the data redundancy, as well as achieving the
improvement in system fault tolerance.
Note - Hardware RAID is supported only on the M8000/M9000
servers on which a RAID-capable onboard device card (IOUA) is
mounted. The RAID-capable IOUA requires a minimum XSCF
firmware with applicable Oracle Solaris OS patches. See the
latest Product Notes for this information.
Note - When the onboard device card is RAID-capable, the
showhardconf(8) command displays Type 2 in the output.
SPARC Enterprise
M8000/M9000 Servers
Site Planning Guide
1-18 A part of values in inches on FIGURE 1-13 to FIGURE 1-16 will
be corrected. For detail, see “M9000 Servers Installation Area” on
page 121.
1-35 For the order number of Vibration-proof bracket and Vibration-
proof feet, see “Miscellaneous Information” on page 125.
SPARC Enterprise
M8000/M9000 Servers
Service Manual
7-8 The mounting location of I/O Unit (IOU) indicated on FIGURE
7-4 will be corrected. For detail, see “I/O Unit (IOU) Mounting
Locations” on page 124."
PCI#0 Name_Property:pci; Card_Type:IOUA;
+ Serial:PP0611T826 ; Type:2;
+ FRU-Part-Number:CA21138-B84X 010AE/371-5000-05 ;
