Working with the Tablet PC

Removing the SIM card

► Open the slot c over (1).

► Pull the SIM card holder out of the slot (2).

► Remove the SIM card from the SIM

card holder (3).

► Push the SIM card holder back

into the slot (4).

► Close the slot c over.

Fujitsu 35
