Fujitsu STYLISTIC Q507 User Manual

Technical data
WLAN specifications
Type of ne twork Intel® Dual Band Wireless-AC 8260
(802.11ac/a/b/g/n WLAN) with Bluetooth v 4.1
2.4 GHz min. 2412, max. 2472
5.8 GHz min. 5180, max. 5825
Transfer r ate 2.412 GHz to 2 .472 GHz
• 1 Mbps / 2 Mbps / 5.5 Mbps / 11 Mbps
• OFDM 6 Mbps / 9 Mbps / 12 Mbps /
18 Mbps / 24 Mbps / 36Mbps / 48 Mbps /
54 Mbps
• MCS0-7(HT20):6.5 - 65 Mbps at SISO
• MCS0-15(HT20):6.5 - 130 Mb ps at MIMO
5.8 GHz to 5.85 GHz
• OFDM 6 Mbps / 9 Mbps / 12 Mbps /
18 Mbps / 24 Mbps / 36Mbps / 48 Mbps /
54 Mbps
• MCS0-7(HT20):6.5 - 65 Mbps at SISO
• MCS0-15(HT20):6.5 - 130 Mb ps at MIMO
• MCS0-7(HT40):13.5 - 135 Mbps at SISO
• MCS0-15(HT40):13.5 - 270 M bps at MIMO
Typical operat
ing distances**
• IEEE 802.11a: 4
9.2 ft. (15 m)
• IEEE 802.11b/g: 98.4 ft. (30 m)
• IEEE 802.11n:
164 ft. ( 50 m)
Number of channels • 2,412 GHz to 2,472 GHz = 11 ch
• 5,8GHzto5,85GHz=21ch
Security • WEP (WEP key: 64/128 bit)
• WPA-Personal (TKIP/AES)
• WPA2-Personal (TKIP/AES)
• WPA-Enterprise (TKIP/AES)
• WPA2-Enterprise (TKIP/AES)
• IEEE 802.1x (TLS/PEAP)
Maximu
m recommended number of computers
to be co
nnected over wireless LAN (during ad
hoc con
nection)
10 unit
s or less ****
* “Wi-Fi base d” indicates that the interconnectivity test of the organization which guarantees the
interconnectivity of wireless LANs (Wi-Fi Alliance) was passe d.
** The operating distances given above increase or decrease d epending on factors such as the
number of walls, reflecting material or interference b y external RF sources.
*** Network key encryption (WEP) o ccurs with the number of bits given above, after deduction of
the fixed length of 24 bits the user may however also set 40 or 104 bits.
**** Depending on the particular practical application, the number of computers which can be
networked is reduced if necessary.
