FUTABA 32MZ-WC User Manual

196
＜
Model Menu (Helicopter)
＞
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
+(/,&237(5
B.Wirelesstunings
To configure the Wireless tunings, set two consecutive
free channels to use for Wireless tunings in SBUS Basic
4/4.
Linkage menu → Function
Example using 13CH and 14CH
1. Select “Gyro setting” on the last page of
Helicopter Model Menu
Before making Wireless tunings, it is necessary to download the setting data from the gyro to the T32MZ-WC via a wired
connection.
Once the gyro data is stored in the T32MZ-WC, if it is the same gyro, there is no need to make a wired connection from the
second time on. If you want to use another gyro, you need to reconnect the cable and download the data.
First, wired connection
Next, Wireless tunings
2.Select "Start"
This will download the gyro data to the T32MZ-WC.
1
2
SETTING
T32MZ-WC
S.I/F
P.BOX
CGY755/CGY760R
1
3.Select "Wireless Tuning"
3
2
4.Items that can be set wirelessly are displayed
4
1. Select “Gyro setting” on the last page of
Helicopter Model Menu
2.Select "Start"
CGYConnectionCable(includedwithgyro)
● Connect the receiver battery (3.5 to 8.4V) to
one of the "AIL" to "S.B2" connectors other
than "RPM" and "P.BOX".
(Do not connect to "RPM" and "P.BOX".)
2 consecutive free channels
Set operation and trim to NULL.
Check that the gyro to be
set matches the EQ ID.
When "GY Settings Transfer" is
selected, the gyro setting data saved
in T32MZ-WC is written to the gyro.
