FUTABA 32MZ-WC - SWH. Detail (Swash Detail Setting); (1) PIT AIL: collective pitch aileron mixing rate; (2) PIT ELE: collective pitch elevator mixing rate; (3) PIT ELE2: collective pitch 2 nd elevator mixing rate

217
＜
Model Menu (Helicopter)
＞
ڀ ŪŲŃƗƒŃŷŤťůŨŃŲũŃŦŲűŷŨűŷŶ
+(/,&237(5
SWH.Detail（SwashDetailSetting）
SWH.Detail（SwashDetailSetting）
The swash detail setting is used to keep the swash plate level at high and low collective pitch to cyclic interactions and cyclic
pitch to collective pitch interactions.
"
6:+'(7$,/
"
screen from the
"
EXPERT MENU 3D
"
screen.
(1) PIT AIL: collective pitch aileron mixing rate
GoingfromMIDtoHIGHandMIDtoLOWcollectivepitchcheckthatthe
swashplateistravelingflatthroughouttheentirerange.
[Settingmethod]Operatethetransmitterstickinthedirectionyouwant
toset.Touchthebuttonlitingreentoenterthesettingmodeandadjust
themixingrate.Dothesamefortheotherside.
Settingranges:30~150%Initialvalue:100%
(2) PIT ELE: collective pitch elevator mixing rate
GoingfromMIDtoHIGHandMIDtoLOWcollectivepitchcheckthatthe
swashplateistravelingflatthroughouttheentirerange.
[Settingmethod]Operatethetransmitterstickinthedirectionyouwant
toset.Touchthebuttonlitingreentoenterthesettingmodeandadjust
themixingrate.Dothesamefortheotherside.
Settingranges:30~150%Initialvalue:100%
(3) PIT ELE2: collective pitch 2nd elevator mixing rate
Thisparameteradjuststhepitchto2ndelevatormixingrate.Therates
canbothbeadjustedindividuallyforbothfullhighandlowcollectivepo
-
sitions.Note:ThissettingisonlyavailableiftheH4-xxswashmodehas
beenselected.
Settingranges:30~150%Initialvalue:100%
(4) AIL PIT: aileron collective pitch mixing rate
Atthemiddlecollectivepitch,checkthatduringrighttoleftandleftto
rightaileronactiontheswashplateisstayinglevelonboththeelevator
andcollectivepitchaxis.Iftheswashplateisrisingorfallingwithaileron
inputs.
[Settingmethod]Operatethetransmitterstickinthedirectionyouwant
toset.Touchthebuttonlitingreentoenterthesettingmodeandadjust
themixingrate.Dothesamefortheotherside.
Settingranges:30~150%Initialvalue:100%
(5) AIL ELE: aileron elevator mixing rate
Thisparameteradjuststheailerontoelevatormixingrate.Theratecan
beadjustedforleftandrightdirectionsindividually.Note:Thissettingis
onlyavailableiftheH4-45swashmodehasbeenselected.
Settingranges:30~150%Initialvalue:100%
(6) AIL ELE2: aileron 2nd elevator mixing rate
Thisparameteradjuststheaileronto2ndelevatormixingrate.Therate
canbeadjustedforleftandrightdirectionsindividually.Note:Thisset
-
tingisonlyavailableiftheH4-45swashmodehasbeenselected.
Settingranges:30~150%Initialvalue:100%
