SWH.Detail（SwashDetailSetting）
SWH.Detail（SwashDetailSetting）
(7) ELE PIT: elevator collective pitch mixing rate
Duringbackandforwardelevatorinputsatmiddlecollective,checkifthe
swashplateisraisingorloweringduringtheinput.
[Settingmethod]Operatethetransmitterstickinthedirectionyouwant
toset.Touchthebuttonlitingreentoenterthesettingmodeandadjust
themixingrate.Dothesamefortheotherside.
Note:ThissettingcannotbeusedwhenH4-00swashmodeisselected.
Settingranges:30~150%Initialvalue:H3-120=50%,exceptH3-120=100%
(8) ELE AIL: elevator aileron mixing rate
Whilemovingtheelevatorbackandforthatmiddlecollective,checkto
makesuretheaileronaxisisstayinglevel.
[Settingmethod]Operatethetransmitterstickinthedirectionyouwant
toset.Touchthebuttonlitingreentoenterthesettingmodeandadjust
themixingrate.Dothesamefortheotherside.
Note:ThissettingcannotbeusedwhenH4-00swashmodeisselected.
Settingranges:30~150%Initialvalue:H3-120=50%,exceptH3-120=100%
(9) ELE ELE2: elevator 2nd elevator mixing rate
Thisparameteradjuststheelevatorto2ndelevatormixingrate.Therate
canbeadjustedseparatelyforupanddowndirectionsindividually.
Note:ThissettingisonlyavailableiftheH4-xxswashmodehasbeen
selected.
Settingranges:30~150%Initialvalue:100%
(10) AIL High / AIL Low: Linkage compensation aileron
AtHIGHpitchandLOWpitchchecktomakesurethattheswashplate
isstayinglevelontheelevatorandcollectiveaxiswhenusingaileron
inputs.Iftheswashplateisrisingorfalling:
[Settingmethod]Operatethetransmitterstickinthedirectionyouwant
toset.Touchthebuttonlitingreentoenterthesettingmodeandadjust
themixingrate.Dothesamefortheotherside.
Note:checkallfourdirections:high/right;high/left;low/right;low/left
Settingranges:0~100%Initialvalue:0%
(11) AIL Dir: Compensation direction of the aileron
IftheaboveData(+/-)correctionfrom0-100isNOTinthecorrectcom-
pensationdirection,changethevaluefrom[+]or[-].
Setting:+/-Initialsetting:+
