111
Reference
Glossary (LCD Display)
The Glossary gives the definition and number of the page that describes the related
function for the symbols displayed on the LCD screen.
1:~5: Point 1 through 5 in the throttle curve
2ND Dual rate function
2PS 2-posion movement for 3CH
3C-DWN 3CH (Down side)
3C-UP 3CH (Up side)
3CH 3rd channel
3PS 3-posion movement for 3CH
A
A.B.S A.B.S. function
AB.P, ABP A.B.S. function (Brake position)
ABS.D, ABSD A.B.S. function (Delay)
ACC-3, ACC3 3CH brake acceleration
ACC-B, ACCB Throttle acceleration (Brake side)
ACC-F, ACCF Throttle acceleration (Forward side)
ACCESS ERROR Access error
ACT(OFF) Function is ready to be activated.
ACT, ACT(ON) Function is on active.
ADJUSTER Adjuster
ALRM Alarm setting
ALT Repetition of ON/OFF of the Return SW
ALWAYS Backlight is always on.
ARRANGE-1,2,3 Function assignment to the 3-posi
tion SW
AT-START Start function, engine cut function
ATL Throttle ATL function
ATS Condition setting for the stick-triggered AT-
START
AUTO-START Start function, engine cut function
B
BABD, B-ABD 3CH brake A.B.S. function (Delay)
BABP, B-ABP 3CH brake A.B.S. function (Brake position)
BACK UP ERROR Back up error
BK-DL, BKDL, BRKDLY Brake mixing (Delay)
BK-RT, BKRT Brake mixing (Rate)
BLHT Backlight ON
BLUE LED: Blue
BOAT Boat mode throttle stick
BRK, BRAK, BRAKE Parameter setting for the brake
side.
BRAKE-MIX Brake mixing function
BRK-EXP, BRKEXP TH-EXP rate at brake side
BT-1,2 Button trim
BUZ-TONE Buzzer tone change
C
C:RES Curve reset
CANCEL Cancellation of the adjuster function
CH-EPA EPA Function
CH-REVERSE Servo reverse function
CH1 > 3 Mixing direction (From 1CH to 3CH)
CH3 3rd channel
CH3 > 1 Mixing direction (From 3CH to 1CH)
CH3ABS 3CH brake A.B.S. function
CH3 POSITION,CH-POSI 3CH position
CONTRAST Screen contrast adjustment
CRV A kind of the TH-EXP curves
CYC, CYCLE, CYCL A.B.S. function (Cycle speed)
D
D/R Steering dual rate
D/R 2ND, D/R2 2nd dual rate function
DIRC-CALL Direct-call function
DISP Display switch ON
DISP-SEL Select the initial screen
DLY Amount of delay
DWN Direction (Down side)
DPAC CAMPac
DT1,2,3 Digital trim
DTY A.B.S. duty ratio
E
E11~E20 Model numbers in the CAMPac
EPA(ATV) EPA function
EXECUTE Execution of Stick adjustment
EXP TH-EXP curve type
EXP3, EXP-3 EXP for 3CH brake
EXP-B, EXPB Throttle EXP (Brake side)
EXP-F, EXPF Throttle EXP (Forward side)
EXP-S, EXPS Steering EXP
F
F50/R50 Throttle mode, Servo movement 5:5
F70/R30 Throttle mode, Servo movement 7:3
F Throttle forward
FAIL SAFE, FAIL-SAFE,F/S Failsafe function
FUNC-DIAL, FUNC-DL Function select, dial function
F-TYP, FUNC-S Function select switch
FWD-TYP Selection of a curve for TH-EXP forward
FWD, FWRD, FORWARD Forward side setting
G
GREEN LED: Green
H
HOLD Function to hold “FAIL SAFE”
HRS HRS (High response) mode
HRS MC SET HRS MC set up function
I
IDL1, IDL-1, IDLE-1 Idle-up function 1
IDL2, IDL-2, IDLE-2 Idle-up function 2
IDLE-UP Idle-up function
INH(OFF) Function is suspended.
INITIALIZE? Initialize?
K
KEY-ON Backlight ON during the button operation
KNB Knob dial
L
LAP RES Timer reset switch
LAP STA Timer start/stop switch
