FUTABA 3VCS User Manual

71
Functions
(Initial screen)
Use the or
button to select the
menu screen.
Press the button.
Use the or
button to select the
function.
Press the button.
Calling the setup screen
* When the direct call button is set,
the setup screen is also called by the
following method:
MENU SELECT
DIRECT SEL
Press the and
button simulataneously.
Press the button set
at this function.
* Calling from menu screen
Use the or button to
select the setup item.
* blinks at the current
setup item.
(Initial screen)
MENU
センターを出すため
に使用する
Subtrim/SUB-TRIM(All channel)
Use this function to adjust the neutral position of the steer-
ing, throttle and channel 3 servos.
Subtrim shifts the entire servo travel range in the set direc-
tion.
Use to adjust the neutral position
* Steering subtrim
* Throttle subtrim
* Channel 3 subtrim
Brake side operation stop method
(Preparation)
-Set the steering and throttle digital trims to the neutral
"0" position. Set CH3 to the center "0" position.
- Preselect setup channel "ST", "TH", or "CH3".
1 (Subtrim adjustment)
Use the (+) or (-) button to adjust the center.
(Each channel can be set similarly.)
2 When ending adjustment, return to the initial
screen by pressing the (END) button 3 times.
Subtrim
ST : L100~R100
TH : B100~F100
CH3 : -100~+100
Initial value : 0
Subtrim/SUB-TRIM(All channel)
