38
Functions
(Initial screen)
Use the or
button to select the
menu screen.
Press the button.
Use the or
button to select the
function.
Press the button.
Calling the setup screen
* When the direct call button is set,
the setup screen is also called by the
following method:
MENU SELECT
DIRECT SEL
Press the and
button simulataneously.
Press the button set
at this function.
* Calling from menu screen
Use the or button to
select the setup item.
* blinks at the current
setup item.
(Initial screen)
MENU
Setup item
TURN : TURN direction
RETURN : RETURN direction
Adjustment range
1~100% (each direction)
Adjustment buttons
- Use the (+) and (-) buttons to make
adjustments.
- Return to the initial value by pressing
the (+) and (-) buttons simultaneously
(approx. 1 sec).
操作時のスピード可変範囲
時間
（約1.5〜0.1秒）
戻りのスピード可変範
囲
（約1.5〜0.1秒）
ス
テ
ィ
ッ
ク
操
作
"TURN"方向
"RETN"方向
Steering Speed/ST-SPEED (Steering system)
Quick steering operation will cause momentary understeering, loss of speed, or spin-
ning. This function is effective in such cases.
Understeering
Spin
Smooth cornering
Steering speed not set Steering speed set
Operation
- This function limits the maximum speed of
the steering servo. (Delay function)
- The steering speed when the steering wheel
is operated (TURN direction) and returned
(RETN direction) can be independently set.
TURN direction
Turning speed adjustment range
(Approx. 1.5 to 0.1 secs)
Stick operation
RETN direction
Return speed adjust-
ment range (Approx. 1.5
to 0.1 secs)
- If the steering wheel is turned
slower than the set speed, the steer-
ing servo is not affected.
Time
Setting example (Steering servo: S9451 / S9351) . . . (Setting criteria)
- Onroad TURN side: Approx. 50~80% RETN side: Approx. 60~100%
- Offroad TURN side: Approx. 70~100% RETN side: Approx. 80~100%
Steering Speed/ST-SPEED (Steering system)
