100
Functions
Trottle mode/THR-MODE
Throttle mode function assignment
1 (To select a throttle stick mode)
Select "TH-STK" by (UP) or (DN) button.
Then select one of the throttle stick modes by (+)
or (-) button.
2 (To select a neutral position)
When "NORMAL" is selected for the throttle stick
mode, "SRV-NT" will be shown on the screen. (It
will not be shown when "BOAT" is selected.)
Move the cursor to "SRV-NT" by (UP) or (DN)
button. Then select one of the neutral positions
by (+) or (-) button.
Throttle stick modes
Normal : Forward and backward
(brake side) movement
Boat : Forward movement only.
Neutral positions
F50/B50: Forward : Back=50% : 50%
F70/B30: Forward : Back=70% : 30%
Neutral position
3 (To end)
To end this procedure and to return to the initial
screen, press the (END) button three times.
