79
Functions
(Initial screen)
Use the or
button to select the
menu screen.
Press the button.
Use the or
button to select the
function.
Press the button.
Calling the setup screen
* When the direct call button is set,
the setup screen is also called by the
following method:
MENU SELECT
DIRECT SEL
Press the and
button simulataneously.
Press the button set
at this function.
* Calling from menu screen
(Initial screen)
MENU
Model Name/MDL-NAME
This function allows you to assign a ten character name to each model memory and
an user name (ten character).
Model name
User name
Model Name/MDL-NAME
Model Name and User Name
1 Move the cursor (blinking) to the column you
want to change using the (DN) or (UP) button.
2 Change the character using the (+) or (-) button.
(Set the model name or user name by repeating
steps 1 and 2 above. )
3 When ending adjustment, return to the initial
screen by pressing the (END) button 3 times.
To Next Page
