FUTABA 3VCS User Manual

86
Functions
(Initial screen)
Use the or
button to select the
menu screen.
Press the button.
Use the or
button to select the
function.
Press the button.
Calling the setup screen
* When the direct call button is set,
the setup screen is also called by the
following method:
MENU SELECT
DIRECT SEL
Press the and
button simulataneously.
Press the button set
at this function.
* Calling from menu screen
(Initial screen)
MENU
ATL Function/TH-ATL(Throttle system)
This function adjusts the "-" side when the braking effect is strong and the "+" side
when the braking effect is weak. This setting is linked to transmitter grip dial BT2.
When BT2 is assigned to another function, set the ATL function with this screen.
Operation
The throttle brake side (when the throttle stick is pushed
forward) brake amount can be adjusted.
Setup Item
RATE: Brake amount
Adjustment buttons
- Use the (+) and (-) buttons to make
adjustments.
- Press the (+) and (-) buttons simulta-
neously (approx. 1 sec) to return to
the initial screen.
ATL function adjustment
1 (Brake amount adjustment)
Use the (+) and (-) buttons to adjust the brake
amount.
- Adjust the - side when the braking effect is strong and the + side when
the braking effect is weak.
2 When ending adjustment, return to the initial
screen by pressing the (END) button 3 times.
Brake amount
0~100%
Initial value: 100%
ATL Function/TH-ATL(Throttle system)
